CASE STUDY

18044: PROJECT FEEDING STEEL TUBES INTO END FINISHER

Feedall Model
Model 1500 Bi-Directional Orienting Conveyor

APPLICATION

Accept Steel Tubes from customer’s conveyor at random onto a Bi-Directional feed
conveyor. Tubes will merge from the in-feed (load) lane onto the orienting lane conveyor
and discharged in a continuous, end-to-end stream.

WIDTH

18” Wide PVC - In-Feed (Load) Lane
12” Wide PVC - Orienting Lane

DRIVE

1/2 HP Gearmotor with 230/460/3/60 Volt-Phase-Cycle – In-Feed (Load) Lane
1/2 HP Gearmotor with 230/460/3/60 Volt-Phase-Cycle – Orienting Lane

PARTS FED (SIZE)

Steel Tubes (0.25”-1.00”Ø x 2.00”-7.00” Long)

FEED RATE

2,000 parts/hour (≈33 parts/minute)
