CASE STUDY

17029: PROJECT FEEDING STEEL BARS INTO INDUCTION HEATER

Feedall Model
Model 1775 Magazine Bar Feeder

APPLICATION

Feed bars from a manually loaded, box container with lift gate. Steel Billets will be loaded from box container into the magazine via a lift gate with hoist. The Billets will be fed in a continuous stream and escaped one at a time onto customer supplied cross-feed conveyor.

WIDTH

8”-19” (Adjustable)

DRIVE

3/4 HP/AC Motor

PARTS FED (SIZE)

Steel Bars (0.562”-0.938”Ø x 8.00”-18.00” Lg.)

FEED RATE

10 Parts/Minute
